VoltFlow Digital Multimeter 6V-24V With Probe
VoltFlow Digital Multimeter 6V-24V With Probe
Quantity
Regular price
$30.59 AUD
Regular price
Sale price
$30.59 AUD
Couldn't load pickup availability
Pins are saved on this device only. Clearing browser history removes them.
View full details
Overview
The VoltFlow Digital Multimeter is a 19-range, 7-function meter for testing, diagnosing, and troubleshooting automotive and general electrical circuits.
Measures DC voltage, AC voltage, DC current, resistance, transistor HFE, temperature, and battery condition. Easy-to-read LCD display with twist dial operation. Supplied with insulated probes, 70cm test leads, 9V battery, and instruction manual. Dimensions: 126mm x 70mm x 28mm.
Specifications
Dimensions: 126mm x 70mm x 28mm
Display: LCD
Battery: 9V (included)
Test Lead Length: 70cm
Low Battery Indicator: Yes
DC Voltage (DCV): 200mV / 2000mV / 20V / 200V / 1000V
AC Voltage (ACV): 200V / 750V
DC Current (DCA): 200µA / 2000µA / 20mA / 200mA / 10A
Resistance: 200Ω / 2000Ω / 20kΩ / 200kΩ / 2000kΩ
Transistor (HFE): NPN/PNP, 0–1000
Battery Test: 1.5V and 9V
DCV Accuracy: ±(0.5%rdg+2dgts)
ACV Accuracy: ±(1.2%rdg+2dgts)
DCA Accuracy: ±(1.0%rdg+2dgts) / ±(1.8%rdg+2dgts) at 10A
Resistance Accuracy: ±(0.8%rdg+2dgts)
Overload Protection (DCV): 500VDC/350VAC (200mV range), 1000VDC/750VAC (all other ranges)
Overload Protection (ACV): 750VAC
Overload Protection (DCA): 500mA/250V fuse (up to 200mA), 10A unfused
Display: LCD
Battery: 9V (included)
Test Lead Length: 70cm
Low Battery Indicator: Yes
DC Voltage (DCV): 200mV / 2000mV / 20V / 200V / 1000V
AC Voltage (ACV): 200V / 750V
DC Current (DCA): 200µA / 2000µA / 20mA / 200mA / 10A
Resistance: 200Ω / 2000Ω / 20kΩ / 200kΩ / 2000kΩ
Transistor (HFE): NPN/PNP, 0–1000
Battery Test: 1.5V and 9V
DCV Accuracy: ±(0.5%rdg+2dgts)
ACV Accuracy: ±(1.2%rdg+2dgts)
DCA Accuracy: ±(1.0%rdg+2dgts) / ±(1.8%rdg+2dgts) at 10A
Resistance Accuracy: ±(0.8%rdg+2dgts)
Overload Protection (DCV): 500VDC/350VAC (200mV range), 1000VDC/750VAC (all other ranges)
Overload Protection (ACV): 750VAC
Overload Protection (DCA): 500mA/250V fuse (up to 200mA), 10A unfused
Features
- 19 ranges across 7 functions — comprehensive electrical measurement capability
- Twist dial operation — simple and fast range selection
- Measures AC and DC — suits vehicle and general electrical testing
- LCD display — clear digital readings in all conditions
- Low battery indicator — alerts when battery replacement is needed
- Supplied with probes, 70cm leads, battery, and manual — ready to use out of the box
Fitment / Notes
- Suits automotive, marine, caravan, and general electrical circuit testing
