Overview
Hella heavy duty battery isolator switch for high-load applications. Rated to 2500A surge at 24V.
Turn knob with removable key — key can only be removed in off position. Continuous load capacity 100A maximum at 60°C ambient with 50mm cable. Silver-plated contacts.
Specifications
Capacity: 2500A / 10 sec @ 24V
Continuous Load: Max 100A @ 60°C ambient (50mm cable)
Terminals: 2 screw connections, 1 nut per bolt
Actuation: Turn knob with removable key
Contacts: Silver-plated
IP Rating: IP53 (connection side), IPX4 (key side)
DIN/ISO: 40050
Continuous Load: Max 100A @ 60°C ambient (50mm cable)
Terminals: 2 screw connections, 1 nut per bolt
Actuation: Turn knob with removable key
Contacts: Silver-plated
IP Rating: IP53 (connection side), IPX4 (key side)
DIN/ISO: 40050
Features
- 2500A surge capacity — rated for the highest load battery main line applications
- Removable key in off position only — prevents accidental battery reconnection
- Silver-plated contacts — reliable connection over long service life
- Plus or minus line selectable — flexible installation
- Heavy duty construction — engineered for commercial and industrial vehicle applications
Fitment / Notes
- IP Rating: IPX4 (key side), IP53 (connection side)
- Note: Continuous load max 100A at 60°C ambient with 50mm cable and ring tongues.
